Select by Type

Select by TypeGeometry of the desired type will be selected.  All other geometry will be deselected.



tog_minusObject Selection Filters dialog box
Object Selection Filters dialog box

Object Selection Filters dialog box

•Selectable Types
Check the box next to the object types that you wish to select.

•Select All / Clear All
Selects or Clears all types selected.
