Array Selected Objects

Array Selected ObjectsAll selected objects will be copied into a uniform grid of objects offset from each other specified distances in x, y, and z.  A dialog will appear where you can input parameters.



tog_minusCommand Prompts

None.
tog_minusBasic Procedure



Screen Activity

Comments

Step 1

Select Array... from Transform menu.

Step 2

The number of objects is displayed.  Use Pick Objects to add more to the selection.



Step 3

Define the XYZ Spacing and # of Copies.



Step 4

Pick OK to complete the Mirror command.


tog_minusDialog Box: Array selected objects
Array selected objects

Array selected objects
tog_minusNumber of objects picked

The number of objects to be arrayed is displayed.  If more items need to be scaled, use the Pick Objects button.
tog_minusXYZ Spacing

The XYZ Spacing is the separation of a given point on an object and the corresponding point on the copied objects.  The object’s size is not considered during this command.
tog_minus# of Copies

There can be a different Number of X, Y or Z Copies made in each direction.
tog_minusNotes

1.If the spacing numbers are all positive, the original object will be the one with the lowest (x, y, z) coordinates.
