User Interface

<< Click to Display Table of Contents >>

Navigation:  Profile-NEST Module >

User Interface

The VisualCAM Profile-NEST module adheres to the Windows standard for user interface design and integrated into the VisualCAD screen seamlessly.



tog_minusMILL Module Displayed

A screen shot of the VisualCAM Profile-NEST module running inside of VisualCAD is shown below:

The Profile-NEST module running inside of VisualCAD

The Profile-NEST module running inside of VisualCAD
tog_minusThe VisualCAM MILL Interface

There are 3 main interface objects created when MILL module is loaded.

1.VisualCAM menu bar entry under VisualCAD menu bar

2.Machining Browser (Mops) window

3.Machining Objects (Mobs)  Browser window
